IDEAL Thermo-Shrink 3/4"x4' Heavy-Wall Heat Shrink, Model 46-609*
HomeStore

IDEAL Thermo-Shrink 3/4"x4' Heavy-Wall Heat Shrink, Model 46-609*

IDEAL Thermo-Shrink 3/4"x4' Heavy-Wall Heat Shrink, Model 46-609*

$11.33

Original: $32.36

-65%
IDEAL Thermo-Shrink 3/4"x4' Heavy-Wall Heat Shrink, Model 46-609*—

$32.36

$11.33

The Story

Description

Ideal Industries Thin-Wall Thermo-Shrink heat shrinkable tubing. Roll of 4' long 3/4" diameter. Suitable for cable range 2 AWG to 250 MCM

Benefits

  • Polyolefin material electrically insulates and protects in-line components, disconnect terminals and splices with its high strength and excellent resilience
  • Use to bundle wires for very flexible light-duty harnesses
  • Highly flame-retardant and flexible; resistant to common fluids and solvents
  • Meets UL 486D 125°C VW-1 600V; Material: No PBB’s, PBBE’s, conforms to ROHS
  • 2:1 shrink ratio; Minimum shrink temperature: 70°C; Operating temperature: -55°C to +125°C
  • RoHS compliant
  • UV resistant

Technical Information

Normal Size: 3/4"
Expanded I.D. (Min.) 0.807"/20.5mm
Nominal Recovered I.D. (Max.): 0.374"/9.5mm
Recovered Wall Thickness +/- 10%: 0.027"/0.69mm
Max. Cable Range: 250MCM
Min. Cable Range: 2 AWG
Heat Shrink Length: 4 ft.
Heat Shrink Type: Thin-Wall

Description

Description

Ideal Industries Thin-Wall Thermo-Shrink heat shrinkable tubing. Roll of 4' long 3/4" diameter. Suitable for cable range 2 AWG to 250 MCM

Benefits

  • Polyolefin material electrically insulates and protects in-line components, disconnect terminals and splices with its high strength and excellent resilience
  • Use to bundle wires for very flexible light-duty harnesses
  • Highly flame-retardant and flexible; resistant to common fluids and solvents
  • Meets UL 486D 125°C VW-1 600V; Material: No PBB’s, PBBE’s, conforms to ROHS
  • 2:1 shrink ratio; Minimum shrink temperature: 70°C; Operating temperature: -55°C to +125°C
  • RoHS compliant
  • UV resistant

Technical Information

Normal Size: 3/4"
Expanded I.D. (Min.) 0.807"/20.5mm
Nominal Recovered I.D. (Max.): 0.374"/9.5mm
Recovered Wall Thickness +/- 10%: 0.027"/0.69mm
Max. Cable Range: 250MCM
Min. Cable Range: 2 AWG
Heat Shrink Length: 4 ft.
Heat Shrink Type: Thin-Wall
